How to eliminate output power oscillation of grid-connected inverter under unbalanced grid voltage?
At present, the main methods to eliminate the output power oscillation of grid-connected inverter under unbalanced grid voltage can be divided into two categories: the first type is to improve the control strategy; the second one is to change the topology of the inverter.
What is a grid connected inverter?
1. Introduction The grid-connected inverter is the vital interface module for distributed generation (DG) systems, including wind power generation, photovoltaic power generation, to be connected to the grid. It can directly determine the value and direction of current and power and is crucial for the safe operation of the grid [1, 2].
What is the frequency oscillation problem in a parallel-inverter-based grid-connected system?
Abstract: This paper addresses the frequency oscillation problem in a parallel-inverter-based grid-connected system. Angular frequency interactions between inverters and the grid exhibit various numbers of complicated characteristics that seriously threaten the connected power system's stable operation.
What if a grid-connected inverter is unbalanced?
Author to whom correspondence should be addressed. Under unbalanced grid voltage faults, the output power oscillation of a grid-connected inverter is an urgent problem to be solved. In the traditional topology of inverters, it is impossible to eliminate power oscillation and simultaneously maintain balanced output current waveform.
What is the power control model of a grid-connected inverter?
In this method, the power control model of each grid-connected inverter is equivalent to a two-terminal network by analogy method, which can be described as a “current source” connected in parallel with a reciprocal of “admittance” and then joined in series with a joint of “admittance.”
How to ensure the output current of grid-connected inverters meets grid codes?
To ensure that the output current of grid-connected inverters meets the grid codes [18, 19], the only way is to set the adjustment coefficient k as 0, which means to use the balanced positive sequence control (BPSC) strategy .
